CHIMERAâ„¢ Range


Revolutionising Wellbore Cleaning

CHIMERA Uni-Blade™
Uni-Blade

CHIMERA Uni-Blade™ is a heavy duty wellbore clean-up scraper suitable for all downhole conditions and with robust, high performance features.

Run separately or as part of a comprehensive wellbore clean-up, the CHIMERA Uni-Blade™ is designed to effectively remove cement and other debris from the casing wall, through reciprocation.

The scraper cage flexes like a spring, to conform to the casing internal surface, to mechanically remove hard debris from the casing. The alloy bronze bearings feature both axial and radial elements to allow extended rotation in harsh environments preventing tool and casing wear. The Heavy Duty version includes an integral string mill. The Standard Duty version comes with a plain external diameter.

  • Solid state scraper cage and centralizers, manufactured from a single billet without the need for springs, bolts or pads
  • Non-rotating design with high performance alloy bronze bearings, compatible with high temperature and chemical applications
  • Optional integral string mill with crushed carbide blades to remove cement
  • Available with all API and premium drill pipe connections

Contact us today for your customised solution or download the product data sheet here for further information.

CHIMERA™ Brush
Brush

The CHIMERA™ Brush is a heavy duty wellbore clean-up brush suitable for all downhole conditions with robust, high performance features.

Run separately or as part of a comprehensive wellbore clean-up, the CHIMERA Brush™ is designed to effectively scrub cement and other debris from the casing wall through reciprocation.

The brush segments are arranged to allow unhindered fluid bypass while circulating through clearly defined flow paths. The brush segments are securely held in dove-tail grooves and cannot come loose downhole. The alloy bronze bearings feature both axial and radial elements to allow extended rotation in harsh environments, preventing tool and casing wear.

  • Stainless steel crimped wire brushes to safely scrub the casing wall to remove residual cement, scale and other debris
  • Centralizers provide centralization and allow rotation of the tool
    body without casing wear
  • Non rotating design with high performance alloy bronze bearings compatible with high temperature and chemical applications
  • Available with all API and premium drill pipe connections

Contact us today for your customised solution or download the product data sheet here for further information.



CHIMERA Heli-Mag™
Heli-Mag

CHIMERA Heli-Mag™ is a heavy duty wellbore clean-up magnet suitable for all downhole conditions and with robust, high performance features.

Run separately or as part of a comprehensive wellbore clean-up, the CHIMERA Heli-Mag™ is designed to capture ferrous metal debris in the wellbore.

The magnetic inserts are arranged along ribs to create a debris trap, by encouraging fluid flow between the ribs, maximizing magnet exposure. The magnetic inserts are securely held in tongued grooves and cannot come loose downhole.

Non-rotating sleeves are mounted on alloy bronze bearings, featuring both axial and radial elements, to allow extended rotation in harsh environments, preventing tool and casing wear.

  • 16 rows of magnets arranged to trap and retain debris in the wellbore Helically twisted body provides offset for magnets to increase effective area
  • Centralizers provide centralization and rotation of the tool body without casing wear
  • Non rotating design with high performance alloy bronze bearings compatible with high temperature and chemical applications
  • Available with all API and premium drill pipe connections
Contact us today for your customised solution or download the product data sheet here for further information.
CHIMERA Eco-Max™
Eco-Max
The Eco-Max™ is a comprehensive solution to improve completion deployment in a cost driven
market. The tool consists of a scraper, brush and high capacity magnet elements integrated onto a
completion deployed mandrel. The Eco-Max™ can be run as part of the permanent completion
string and eliminates the need for a dedicated wellbore clean-up run.
  • Single piece mandrel complete with connections becomes an integral component of the completion
  • Scraper cage manufactured from single piece mandrel without the need for springs, bolts or pads
  • All components can be supplied with compatible metallurgy
  • Mandrel ID is matched to tubing ID to prevent restrictions
  • Available with any tubing connection to run directly on the completion tubing
Contact us today for your customised solution or download the product data sheet here for further information.
